FSP Group UK Medical

Medical PSU

FSP Group has comprehensive medical PSU by ATX, AC/DC adapters, and AC/DC open frame. All products have undergone quality verification, certification, and production control.All of FSP's medical grade power supplies fully comply with a medical industry safety standard and are highly robust and reliable.

FSP Group UK Medical PSU

Medical PC/ATX PSU

  • Medical IEC 60601-1, EN 60601-1, ANSI/AAMI ES 60601-1 approval

  • Comply with Medical IEC 60601-1-2 EMC standard

  • Comply with Intel ATX 12V Rev 2.2 design guide

  • Output power from 180W to 700W

  • Real time battery backup feature for Lead-Acid battery

FSP250-60MPC FLEX Power Supply unit with 250W and fully complied with IEC60601-1

FSP250-60MPC

This product is PC power in the flex form factor 190 × 82 × 41mm, which maximum output power is 250W and efficiency is 82%85%82%. The unit approved medical safety and certified EMC medical standard, and is designed for medical applications.

  • Certified Medical Safety IEC 60601-1

  • Full Range Input 90-264 VAC

  • 220/250W

  • Active PFC Circuit

  • High Efficiency Certified 80 PLUS

  • Over Voltage/ Over Current/ Short Circuit Protections

FSP350-70MU

This product is PC power in the 1U form factor 190 × 100 × 41mm, which maximum output power is 350W and efficiency is 80%80%80%. The unit approved medical safety and certified EMC medical standard, and is designed for medical applications.

  •  Certified Medical Safety IEC 60601-1

  •  Full Range Input 90-264 VAC

  •  300/350W

  •  Active PFC Circuit

  •  High Efficiency Certified 80 PLUS

  •  Over Voltage/ Over Current/ Short Circuit Protections

FSP250-60MPC Flex Medical Power Supply Unit with fully comply with IEC60601-1
FSP350-70MU 350W medical power supply unit The unit approved medical safety and certified by EMC

FSP500M-80PA

This product is PC power in the 1U form factor 220 × 100 × 41mm, which maximum output power is 500W and efficiency is 87%90%87%. The unit approved medical safety and certified EMC medical standard, and is designed for medical applications.

  •  Certified Medical Safety IEC 60601-1

  •  Full Range Input 90-264 VAC

  •  400/500W

  •  Active PFC Circuit

  •  High Efficiency Meet 80 PLUS GOLD

  •  Operating Altitude 5,000M

  •  Secondary Side 3.3V/5V Outputs DC-DC Design

  •  Over Voltage/ Over Current/ Short Circuit/ Over Temperature Protections

FSP500-70MPE

This product is PC power in the PS2 form factor 140 × 150 × 86mm, which maximum output power is 500W and efficiency is 78%. The unit approved medical safety and certified EMC medical standard, and is designed for medical applications.

  •  Certified Medical Safety IEC 60601-1

  •  Full Range Input 90-264 VAC

  •  400/500W

  •  Active PFC Circuit

  •  Operating Altitude 5,000M

  •  Secondary Side 3.3V/5V Outputs DC-DC Design

  •  Over Voltage/ Over Current/ Short Circuit Protections

FSP500-70MPE 500W ATX Medical power supply unit certified by IEC60601-1
FSP700-70MPB 700W ATX Medical power supply unit certified by IEC60601-1

FSP700-90MPB

This product is PC power in the PS2 form factor 165 × 150 × 86mm, which maximum output power is 700W and efficiency is 82%85%82%. The unit approved medical safety and certified EMC medical standard, and is designed for medical applications.

  • Certified Medical Safety IEC 60601-1

  •  Full Range Input 90-264 VAC

  •  600/700/900W

  •  Active PFC Circuit

  •  High Efficiency Meet 80 PLUS BRONZE

  •  Over Voltage/ Over Current/ Short Circuit Protections

How it works
FSP Group UK wall mount medical adapter

Medical Wall Mount & Adapter 15W - 90W​

  • Medical IEC 60601-1, EN 60601-1, ANSI/AAMI ES 60601-1 approval

  • Comply with  Medical IEC 60601-1-2 EMC standard

  • Completed product line & option for various output voltage

  • High efficiency comply with CEC Level 5

  • Low power consumption for no load condition

  • Output power from 15W to 90W

FSP027M-KSM-U

This product is high efficiency wall mount adapter, which output voltage is 10V and maximum output power is 27W. The unit is shipped with interchangeable USA AC plug, European/UK/Australian AC plug can be purchased from the factory. The unit approved medical safety and certified EMC medical standard, and is designed for medical applications.

  •  Certified Medical Safety IEC 60601-1

  •  Input Voltage Range 80-264 VAC

  •  20/27/30W

  •  DOE Energy Efficiency Level VI

  •  No Load Power Consumption ≦ 0.1W

  •  Operating Altitude 5,000M

  •  Over Voltage/ Over Current/ Short Circuit Protections

  •  Compliant with RoHS requirement

FSP027M-KSM-U Medical Wall Mount adapter 27W 10V 2.7A interchangeble plug. Comply with 60601

FSP030M-DGA

FSP030M-DGA 30W medical adapter. Ideal option for small wattage medical system or pc

This is a high-efficiency series AC/DC switching power supply that can deliver 30W continuous output power for the 15V model. High efficiency feature comply with DOE Level VI & ErP tier II. Compact dimension with an IEC320/C14 inlet to mate with interchangeable cord for world-wide use. All models meet EN55011, EN55032 and FCC class B emission limits.

  • No Load Power Consumption ≦ 0.1W

  • BF class insulation

  • 12V/15V/18V Output Voltage Support

  • PE and RETURN isolated

  • Operating Altitude 5,000M

  • OVP, OCP & Shorted Protections

FSP065-DGBM1

This product is high efficiency desktop adapter with IEC 320/C6 AC inlet, which output voltage is 15V and maximum output power is 65W. The unit approved medical safety and certified EMC medical standard, and is designed for medical applications.

  •  Certified Medical Safety IEC 60601-1

  •  Input Voltage Range 90-264 VAC

  • 12V/15V/19V/24V Output Voltage Support

  •  DOE Energy Efficiency Level VI

  •  No Load Power Consumption ≦ 0.21W

  •  Operating Altitude 5,000M

  •  Meet EN55011 and FCC Class B

FSP065-DGBM1 65W Medical Adapter 15V 0A. Complied with IEC 60601-1
FSP090-RHBM1 90W adapter with 15V. Certified by medical standard, designed for medical application

FSP090-RHBM1

This product is high efficiency desktop adapter with IEC 320/C6 AC inlet, which output voltage is 15V and maximum output power is 65W. The unit approved medical safety and certified EMC medical standard, and is designed for medical applications.

  •  Certified Medical Safety IEC 60601-1

  •  Input Voltage Range 90-264 VAC

  • 12V/18V/19V/24 Output Voltage Support

  •  DOE Energy Efficiency Level VI

  •  No Load Power Consumption ≦ 0.21W

  •  Operating Altitude 5,000M

  •  Meet EN55011 and FCC Class B

FSP Group UK Medical Power Supply Unit

Medical Adapter 90W - 220W​

  • Medical IEC 60601-1, EN 60601-1, ANSI/AAMI ES 60601-1 approval

  • Comply with  Medical IEC 60601-1-2 EMC standard

  • Completed product line & option for various output voltage

  • High efficiency comply with CEC Level 5

  • Low power consumption for no load condition

  • Output power from 90W to 220W

FSP120M-KBA

FSP120M-KBA AC/DC switching power supplies is BF Class 120w continuous output power with an IEC320/C14 inlet to mate with interchangeable cord for world-wide use. Low profile and high-efficiency features with excellent IP54 water proof feature. EMI meet EN55011 Class B, is designed for medical application.

  • Class I Design, IEC 320/C14 AC Inlet

  • IP 54 water proof

  • 19V/24V/36V Output Voltage Support

  • Meet EU CoC EPS V5 tier 2

  • Meet DOE Level VI

  • BF Class

  • Low profile at 28 mm

FSP150M-ABA 150W medical adapter 19V. Complient with RoHS requirement
FSP120M-KBA BF Class 120w continuous output power with an IEC320/C14 inlet

FSP150M-ABA

This product is high efficiency desktop adapter with IEC 320/C14 AC inlet, which output voltage is 19V and maximum output power is 150W. The unit approved medical safety and certified EMC medical standard, and is designed for medical applications.

  • Certified Medical Safety IEC 60601-1

  •  Input Voltage Range 90-264 VAC

  • 12V/15V/19V/24V Output Voltage Support

  •  DOE Energy Efficiency Level VI

  •  No Load Power Consumption ≦ 0.21W

  •  Operating Altitude 5,000M

  •  Over Voltage/ Over Current/ Short Circuit/ Over Temperature Protections

  •  Compliant with RoHS requirement

FSP200-KBAM1

This product is high efficiency desktop adapter with IEC 320/C14 AC inlet, which output voltage is 19V and maximum output power is 200W. The unit approved medical safety and certified EMC medical standard, and is designed for medical applications.

  • Certified Medical Safety IEC 60601-1

  •  Input Voltage Range 90-264 VAC

  • 19V/24V/28V/36V Output Voltage Support

  •  DOE Energy Efficiency Level V

  •  No Load Power Consumption ≦ 0.5W

  •  Over Voltage/ Over Current/ Short Circuit/ Over Temperature Protections

  •  Compliant with RoHS requirement

FSP250M-KAA 250W medical adapter 24V pproved medical safety and certified EMC medical standard, and
FSP200-KBAM1 200W medical adapter 19V IEC 60601-1 Compliat with RoHS requirement

FSP250M-KAA

This product is high efficiency desktop adapter with IEC 320/C14 AC inlet, which output voltage is 24V and maximum output power is 250W. The unit approved medical safety and certified EMC medical standard, and is designed for medical applications.

  • Certified Medical Safety IEC 60601-1

  •  Input Voltage Range 80-264 VAC

  • 12V/19V/24V/30V/36V/48V Output Voltage Support

  •  DOE Energy Efficiency Level VI

  •  No Load Power Consumption ≦ 0.15W

  •  Operating Altitude 5,000M

  •  Over Voltage/ Over Current/ Short Circuit Protections

  •  Compliant with RoHS requirement
